Characteristics:
Model | BRC2500 BRC3000 BRC3500 |
Screen Size | 2500 mm 3000mm 3500mm |
Repeat | 640mm (Standard) 400-2500 mm (Optional) |
Resolution | 360 dpi (Standard) /508 /1016/1440 dpi (Optional) |
Laser Channel | 16 channels(Standard) / 24 channels (Optional) |
Repeat Accuracy | +/- 0.02mm |
Imaging Light Source | 405 nm Laser Diode |
Engraving Speed | 6-8min /m2 ( 16 Laser Channel, Repeated 640nm) |
Acceptable File Format | BMP/TIFF |
Interface | USB |
Ambient Temperature | Temperature : 8 - 26 Celcius Degree, Humidity: 30-50 %, Yellow light |
Power | 1.5 KW/220 V, 50 Hz |
Dimension | 3950 mm x 750mm x 12200 mm (BRC2500) 4450 mm x 750mm x 12200 mm (BRC3000) 4950 mm x 750mm x 12200 mm (BRC3500) |
Net Weight | 1000 Kg (BRC25000)/1100Kg (BRC3000)/ 1200Kg (BRC3599) |
